Relé de Sobrecarga Térmica 3 polos 1NA + 1NC 18-25A ABB 1SAZ211201R1051

Relé de Sobrecarga Térmica 3 polos 1NA + 1NC 18-25A ABB 1SAZ211201R1051

Condición: NUEVO SELLADO.

Este relé de sobrecarga térmica ABB TA25 está diseñado para proteger motores eléctricos. Cuenta con un contacto auxiliar normalmente abierto (NA) y uno normalmente cerrado (NC). Su clase de disparo es 10A y permite reinicio manual o automático. Es compatible con contactores de la serie A de ABB, específicamente los modelos A9 a A30.

Especificaciones

• Product ID: 1SAZ211201R1051
• Extended Product Type: 1SAZ211201R1051
• Product Net Weight: 0.17 kg
• Product Net Width: 44 mm
• Product Net Height: 80 mm
• Description: Thermal Overload Relay | TA25DU-25 (1SAZ211201R1051)
• Product Net Depth: 94 mm
• Degree of Protection: Housing IP20 Main Circuit Terminals IP10
• Ambient Air Temperature: Operation -25 ... +55 °C Operation Compensated -25 ... +55 °C Storage -40 ... +70 °C
• Standards: IEC/EN 60947-1 IEC/EN 60947-4-1 IEC/EN 60947-5-1 UL 60947-1 UL 60947-4-1
• Rated Impulse Withstand Voltage (U_imp): Auxiliary Circuit 6 kV Main Circuit 6 kV
• Rated Insulation Voltage (U_i): 690 V
• Number of Poles: 3
• Rated Frequency (f): Auxiliary Circuit 50 Hz Auxiliary Circuit 60 Hz Auxiliary Circuit DC Main Circuit 60 Hz Main Circuit 50 Hz Main Circuit DC
• Power Loss: at Rated Operating Conditions per Pole 1.5 ... 2.9 W
• Suitable For: A9 A12 A16 A26 A30 A40 AL9 AL12 AL16 AL26 AL30 AL40
• eClass: 7.0 27371501
• Tightening Torque: Auxiliary Circuit 1 ... 1.3 N·m Main Circuit 1.5 ... 1.9 N·m
• Mounting Position: Position 1 to 4
• Number of Auxiliary Contacts NO: 1
• Number of Auxiliary Contacts NC: 1
• Connecting Capacity Main Circuit: Flexible with Ferrule 1/2x 1.5 ... 4 mm² Flexible 1/2x 1.5 ... 4 mm² Rigid 1/2x 1.5 ... 6 mm²
• GOST Certificate: 1SAA941000-2704
• Maximum Operating Voltage UL/CSA: Main Circuit 600 V AC
• Maximum Operating Altitude Permissible: 2000 m
• Tightening Torque UL/CSA: Auxiliary Circuit 12 in·lb Main Circuit 12 in·lb
• Connecting Capacity Auxiliary Circuit: Flexible with Ferrule 1/2x 0.75 ... 2.5 mm² Flexible 1/2x 0.75 ... 2.5 mm² Rigid 1/2x 0.75 ... 4 mm²
• Country of Origin: Germany (DE)
• Wire Stripping Length: Auxiliary Circuit 9 mm Main Circuit 12 mm
• GL Certificate: 1SAA941000-0403
• Connecting Capacity Main Circuit UL/CSA: Flexible 1/2x 16-8 AWG Stranded 1/2x 16-8 AWG
• Ampere Rating UL/CSA: 25 A
• Number of Protected Poles: 3
• Lead Time: 7 day(s)
• EAN: 4013614216633
• Made To Order: No
• Product Sales Status: Inactive
• Quote Only: No
• Minimum Order Quantity: 1 piece
• Customs Tariff Number: 85364900

Peso informado por el distribuidor: Net Weight : 0.17 kg
